FAR2228BB

Radars FR & FAR series Ref : IMD0328302B

BLACK BOX RADAR IMO X BAND 25kW - ARPA - 96 MN - 220 VAC (LESS RADIATOR LESS CABLE)

PRICE : NC

Description

IMO APPROVED

The Black Box FAR-2xx8 BB marine radar series is IMO Cat. 1 , Cat. 2 and Cat. 3 compliant.

  • Cat 1 in combination with the following monitors FURUNO MU-231, FURUNO MU-270W, HATTELAND 23", 26", 27", 32", 55"
  • Cat 2 in combination with the following FURUNO MU190, HATTELAND 19", 20" and 24" monitors
  • Cat 3 in combination with the following monitors FURUNO MU-152, HATTELAND 15" monitors

Automatic Clutter Elimination (ACE)

This new feature allows the improvement of target visualization through a dedicated ACE command. Once activated, the system automatically adjusts the clutter, gain, anti-sea and anti-rain filters based on the user's preset (calm/rough sea/heavy rain).

Fast Target Tracking™ (ARPA)

The target tracking™ (ARPA) function has been significantly improved by significantly reducing the target acquisition time. All the new FAR-15XX series nautical radars feature the advanced ARPA 50 fast tracking targets acquisition feature with which the nautical radar is able to lock on to targets automatically in just a few moments.

Wide DISPLAY COMPATIBLE

The FAR-2xx8 series provides compatibility with WIDESCREEN format monitors also in the IMO version. The WIDE approved monitors are the FURUNO MU-270W and the HATTELAND models from 26" to 55". Despite the different sizes, the number of PPI remains unchanged in order to clearly show on the screen the data necessary for navigation as per legislation. The convenient InstantAccess bar™ allows, through a series of very intuitive icons, to change the radar settings with a simple click of the trackball.

RADAR OVERLAY ON ECDIS AND MAXSEA TIMEZERO

As on other nautical radar models, the FAR2XX8 series also allows the overlapping of the radar beat (Overlay) both on ECDIS devices and on MaxSea TIMEZERO software. An Ethernet connection between the two peripherals is sufficient to activate this function.

* required for HUB-100 or HUB-3000 Switching Hub connection.

Interswitch FUNCTION

It is possible to connect different series of nautical radars including: FAR-2xx8, FAR-2xx7, FAR-3xx0 and FAR-15x8*.

* The HUB-100 is sufficient for the connection of 2 nautical radars in the network, while the HUB-3000 is necessary for 3 or more devices. Both provided as OPTIONAL.
* On the other hand, the connection with the FAR-15x8 model is only available in the REPEATER version.

CONTROL UNIT

The FAR-2XX8 series uses an intuitive professional keyboard with dedicated functions that can be recalled with a simple click.


Product advantages

  • IMO category 1/2/3 certified
  • Improved performance
  • Fast Target Tracking™
  • Wide Monitors
  • Radar echo overlay on ECDIS and SW MaxSea TIMEZERO
  • AIS display
  • Interswitch function
  • The traditional keyboard


Features

The FAR-22x8 Black box series of nautical radars, combined with FURUNO or HATTELAND monitors from 19" to 55", is certified IMO Cat.1 and Cat.2. The available power is 12 or 25 kW for the X-band models and 30 kW for the S-band models. The SSD (Solid State) version without MAGNETRON is also available for the S-band model. Compared to the previous series, the FAR-2xx8 line shows significant improvements in performance thanks to the newly designed processor and antenna. Many functions useful for navigation have been implemented, such as the Automatic Clutter Elimination function and Fast Target Trakcing™ for easier and more comfortable use for the user. The retrofit with the previous series FAR-2xx7 is very simple, the unit has in fact the same dimensions and there is the possibility, through Optional KITS, to use the same keyboard, display and antenna cables.


In the box

1 x PROCESSOR UNIT
1 x CONTROL UNIT
1 x SCANNER UNIT


Videos

Discover Furuno FAR 2xx8 series: X-band and S-band IMO approved with solid state technology
Nautical Radar and Weather Radar Furuno | World leader in navigation electronics
Fast Target Tracking™ | Radar Technology
ACE Mode | Radar Technology
Echo Analysis | Target Analyzer™ | Radar Technology

Parts and accessories

00152327000 OP03-258-1 RP BOARD INSTALLATION KIT RPU025-E CARTE MAPMEDIA NC
00125989000 S03-92-15(8P) SIGNAL CABLE ASSY. 03S001360 NC
00125990000 S03-92-30(8P) SIGNAL CABLE ASSY. 03S001360 NC
00125991000 S03-92-40(8P) SIGNAL CABLE ASSY. 03S001360 NC
00125992000 S03-92-50(8P) SIGNAL CABLE ASSY. 03S001360 NC
00142121000 SP03-17641(BOX) SPARE PARTS PSU-014/RPU-025 NC
00143754000 XH10P-W-6P L=20M CABLE ASSEMBLY 03S9610-5 NC
00143755000 XH10P-W-6P L=30M CABLE ASSEMBLY 03S9610-5 NC
00148924000 XH10P-W-5P-A L=1.5M CABLE ASSEMBLY 03S9698-1 - Replaced by 00159584000 NC
00148947000 OP03-245 FLUSH MOUNT KIT RCU-014B NC
00149658000 OP03-247-3 LAN SIGNAL CONVERTER RSB-128 XBAND 2218/2228 NC
00149690000 OP03-252 DVI-BNC CABLE KIT RPU-025 506,45 € With VAT (20%)
00150529000 OP03-254-3 PM32 INSTALLATION KIT OP03-254-3 PM KIT X-BAND NC
00150773000 OP03-257 ANTENNA REINFORCEMENT KIT RSB-128/130 NC
00003329400 HUB-3000-MIJ INTELLIGENT HUB NC
WV-100 WAVE ANALYZER WV-100 WAVE ANALYZER SOFTWARE WAVE ANALYZER SOFTWARE NC
00158581000 OP03-265 PM MODIFICATION KIT 1 383,86 € With VAT (20%)
00159584000 XH10P-W-5P-A L=1.5M CABLE ASSEMBLY 03S9698-2 92,08 € With VAT (20%)
00159585000 XH10P-W-5P-A L=10M CABLE ASSEMBLY (RCU-RCU) 03S9698-2 196,86 € With VAT (20%)
00159586000 XH10P-W-5P-A L=20M CABLE ASSEMBLY (RCU-RCU) 03S9698-2 NC
00159587000 XH10P-W-5P-A L=30M CABLE ASSEMBLY (RCU-RCU) 03S9698-2 369,65 € With VAT (20%)
00820664000 S03-9-5(8-8P) SIGNAL CABLE ASSY. NC
00820665000 S03-9-10(8-8P) SIGNAL CABLE ASSY. NC
00820916000 S03-9-15(8-8P) SIGNAL CABLE ASSY. 15M NC
00853562000 OP03-182 CLAMP ASSEMBLY RCU-014 NC
00853563000 FLUSHMOUNT KIT FP03-09870 RCU-014/015/016 NC
00854246000 CP03-28901 CONNECTEUR 59,53 € With VAT (20%)
EXU00001039 ICE MODE UNLOCK CODE FOR FAR2X - 33 904,00 € With VAT (20%)
00124771000 XH10P-W-5P-A L=30M CABLE ASSEMBLY (RCU-RCU) 03S9698-1 - Replaced by 00159587000 NC
HUB-100 HUB-100 SWITCHING HUB INTERSWITCH FAR-28X7 NC
00008335500 RJB-001 JUNCTION BOX RADAR PER CAVI RADAR - NC
00113296010 DVI-D/D S-LINK 5M DVI-D/D S-LINK 5M 03S9657-4 NC
00113398010 DVI-D/D S-LINK 10M CABLE EQUIPE DVI 10M 03S9658 829,00 € With VAT (20%)
00116789010 MOD-Z072-050+ CAVO LAN 5M CONNETTORI RJ45/RJ45 PER HUB 82,00 € With VAT (20%)
00120805000 CP24-02900(10M) INSTALLATION MATERIALS NC
00120806000 CP24-02910(20M) INSTALLATION MATERIALS NC
00120807000 CP24-02920(30M) INSTALLATION MATERIALS NC
00124769000 XH10P-W-5P-A L=10M CABLE ASSEMBLY (RCU-RCU) 03S9698-1 NC
00124770000 CABLE ASSEMBLY (RCU-RCU) XH10P-W-5P-A L=20M 03S9698-1 - Replaced by 00159586000 270,68 € With VAT (20%)
00004011000 (Clock & Data + NMEA0183) AD100 Gyro converter NC
00003684800 GD-2887 RADAR INTERFACE KIT 5 239,08 € With VAT (20%)
00003658700 RCU-031-E CONTROL UNIT NC
00125258000 DSUB9P-X2-A-L5M CABLE ASSEMBLY 24S104360 NC
00125259000 DSUB9P-X2-A-L10M CABLE ASSEMBLY 24S104360 334,72 € With VAT (20%)
00125432000 DE-ICER KIT FAR2218/FAR3210 OP03-226 DE-ICER KIT RSB-128 NC
00003428600 RCU-016B CONTROL UNIT NC
00003428400 RCU-015B-S CONTROL UNIT RADAR PER FAR-2XX8 TRACKBALL CON CAVO DA 10M NC
HUB-3000 HUB-3000 INTERSWITCH/HUB INTELLIGENT HUB - NC
00125987000 RW-00135-L40M CABLE EQUIPE SIGNAL 40M 03S001352 1 592,89 € With VAT (20%)
XN12CF XN12CF 4FT (FAR32x0B/FAR22X8B) NC
XN20CF XN20CF 6.5FT (FAR32x0B) NC
XN24CF XN24CF 8FT (FAR32x0B) NC
00125983000 RW-00135-L15M CABLE EQUIPE SIGNAL 15M 03S001352 NC
00125986000 RW-00135 CAVO ANTENNA 30M PER FAR-2XX8 FAR-3000 03S001351 NC
00125988000 RW-00135-L50M CABLE EQUIPE SIGNAL 50M 03S001351 NC
00003425100 RPU025-AE2S-S PROCESSEUR FAR22x8 24rpm NC
00003499700 RSB-128-106NN SCANNER UNIT 1SET NC
00003666300 RCU-014B-E-S CONTROL UNIT CHINA NC
